Product label: RVLU B x H

RVLU Snow shield

NORDexternal

​​​RVLU snow shield is designed to protect supply air openings. Very good resistance to water and snow penetration.
RVLU louvres meet the requirements of the LVI-RYL and SFS 5358 standards.

Dimensions:
Snow shields are manufactured for all sizes of rectangular supply air openings.
Minimum size 500×500 mm.
Sizes over 2000×1800 mm are built in modules. The tolerance of B and H measures is -2/-5 mm.
Standard color is RAL 7000.
Custom colors are available from the RAL K7 Classic color chart, which includes all 213 RAL CLASSIC colors.
Powder coating is used to enhance design and corrosion resistance. Products are coated with a polyester powder paint based on TGIC-free polyester resin. Polyester paints are UV-resistant and weather-resistant and are therefore well suited for outdoor use.
The thickness of the paint layer is 60-80 μm. The lifespan of the surface coating depends on environmental conditions, ranging from 20 to 50 years.

RVLU Snow shield - Product Sheet pdf
RVLU Installation pdf
NORDexternal - External louvres pdf
NORDexternal - Declaration of Conformity pdf
Material Zn, H, ZM
Width 500-2000 mm
Height 500-1800 mm
Special colors RAL K7
